EURVET Good Quality Medical Veterinary Animals Hospital clinic vet ct system veterinary ct scan machine price
Apple Shopping Event
Hurry and get discounts on all Apple devices up to 20%
Sale_coupon_15
19 in stock
19 in stock
15
People watching this product now!
Payment Methods:
Description
- Origin: Mainland China
- Certification: CE
- Place of Origin: Anhui, China
- Brand Name: EURVET, EURVET
- Model Number: TC-460, TC-460
- Properties: Veterinary CT
- Product name: Veterinary Cone Beam Computed Tomography
- Quality Certification: CE ISO
- Instrument classification: Class II
- Power capacity: Not less than 3.5 kVA
- Bed size: 1850mm*550mm*730mm, deviation±5%
- Scanning frame size: 1670mm*810mm*1600mm, deviation±5%
- Bed surface translation range: 0~800mm deviation±5%
- Bed lifting range: 0~150mm deviation±5%
Welcome to our store! I am Yuki, Have a good day! WhatsApp : +86-18711103320, yuki62134@gmail.com
|
EURVET Good Quality Medical Veterinary Animals Hospital clinic used vet ct system veterinary ct scan machine price
|
|
|
||
|
Configuration
|
|
TC-460
|
||
|
Power requirements
|
Input voltage
|
Single phase AC220V
|
||
|
|
Supply frequency
|
50Hz
|
||
|
|
Power capacity
|
Not less than 3.5 kVA
|
||
|
Mechanical capacity
|
Bed size
|
Length, width and height: 1850mm×550mm×730mm, deviation±5%
|
||
|
|
Scanning frame size
|
Length, width and height: 1670mm×810mm×1600mm, deviation±5%
|
||
|
|
Bed surface translation range
|
0~800mm deviation±5%
|
||
|
|
Bed lifting range
|
0~150mm deviation±5%
|
||
|
|
Bearing
|
50kg
|
||
|
Electric power
|
Maximum pulse fluoroscopic output electrical power
|
1.875kW(15mA,125kV,10s)
|
||
|
|
Maximum continuous fluoroscopic output electrical power
|
1.5kW(12mA,125kV,20s)
|
||
|
|
Standard pulse fluoroscopy output electrical power
|
1.6kW(16mA,100kV,10s)
|
||
|
|
Maximum continuous fluoroscopic output electrical power
|
1.4kW(14mA,100kV,20s)
|
||
|
Loading factors and control
|
Tube voltage/kV
|
50kV~125kV, adjust as per levels, adjustable steps of 1kV, deviation ≤±10%
|
||
|
|
Tube current/mA
|
1mA~16mA, adjust as per levels, adjustable steps of 1mA, accuracy conforms to ±1mA
|
||
|
|
Loading time/ms
|
24s, based on external trigger loading time
|
||
|
Imaging performance
|
Imaging size
|
307.2mm×245.7mm
|
||
|
|
Spatial resolution
|
≥1.7lp/mm
|
||
|
|
Imaging time
|
≤40s
|
||
Exclusive Scanning and lmaging System
For High-resolution lmages
Dynamic Range Pixel Array Detector
Amorphous Silicon Cesium lodide
Active area: 25 cm x 30 cm, pixel pitch: 120 um
Lossless image reconstruction: Large-angle cone beam, true isotropic voxel
(identical length, width and height), and zero loss of axial image details
A slice thickness of 0.24 mm, high spatial resolution, and rich details
Amorphous Silicon Cesium lodide
Active area: 25 cm x 30 cm, pixel pitch: 120 um
Lossless image reconstruction: Large-angle cone beam, true isotropic voxel
(identical length, width and height), and zero loss of axial image details
A slice thickness of 0.24 mm, high spatial resolution, and rich details
Storage Room
A handy space for medical supplies
Table Moving by One Touch
Motorized pushing, lfting and lowering
V-shaped Mattress and Auxiliary Belt
ldeal for the immobilization of animals
More information, please contact me!
Q1: What is the advantage about your company? A: We are professional exporter of veterinary equipment and pet grooming products with 20 years’ rich experience. We can give your suitable suggestions and solutions. Q2:Is there a discount? A: Different quantity has different discount. Q3: How to confirm the Product Quality before placing orders? A: You can buy 1 pc sample firstly. Or you can send us your detailed specifications and requests, we will customzied the products according to your requests. Q4: How do you treat quality complaint? A: First of all, our quality control will reduce the quality problem to near zero. If there is a real quality problem caused by us, we will send you free accessories for replacement or refund your loss on the basis of providing the video or photos; If any damage caused by shipping forwarder, please help to take video or photo at the first time at the port before you accept it. We will talk to forwarder directly to solved it. Q5: What is your warranty? A: Most of our products warranty are 1 year or 2 years for free, and a life-long maintenance. Q6: How about delivery leadtime? A: Delivery lead time: Usually about 7-25 working days after payment confirmed. Q7: How to start orders or make payments? A: Proforma invoice will be sent firstly after confirming your order, it will enclosed our bank information. Payment by T/T, credit card, Western Union or Paypal, etc. Q8: How to contact us ? A: You can chat with us by Trademanager, Online messages, etc.You can choose your interested products and send an inquiry, dial our telephone directly, or send an email to us directly, you will get our reply within 8 hours.
